HDPE Fittings
Explore our durable and high-density HDPE fittings designed for secure, leak-free performance in demanding piping systems. Ideal for water, gas, and industrial applications, our corrosion-resistant selection ensures long-lasting reliability. Find the right electrofusion, butt weld, or compression fittings for your next project.
- Material: PE100 (Third-generation, high-density pipe-grade polyethylene virgin material)
- Minimum Required Strength (MRS): 10.0 MPa (1450 psi)
- Hydrostatic Design Basis (HDB): 11 MPa (1600 psi) @ 20°C/23°C
- Allowable Compressive Strength: ~7.93 MPa
- Tensile Strength at Yield: ~23 – 26 MPa (3300 – 3770 psi)
- Elongation at Break: >600% to >800% (highly ductile)
- Modulus of Elasticity (50 years): ~200 MPa (approx. 1000 MPa short-term flexural modulus)
- Flexural Modulus: ~1000 MPa
- Poisson’s Ratio: 0.45
- Thermal Expansion Coefficient: 1.3 × 10⁻⁴ °C⁻¹
- Pressure Ratings: Designed to match the connected pipe’s PN rating or SDR (e.g., SDR 11 for PN16, SDR 17 for PN10).
- Available Diameters: 16 mm up to 300 mm+
- Easy to handle, transport, and install
- Highly corrosion and abrasion resistant
- Weatherproof for underground applications
- Maintains water taste and quality — safe for drinking water
- Withstands high impact and underground movement without cracking
- Reliable supply and delivery across Rwanda.
- On-site technical and installation guidance.
- Dedicated after-sales and customer service team.
- Wide network of distributors for faster access.
- Consistent quality and support for every project size.
- Excellent surface hardness and tensile strength with a high safety coefficient.
- Superior anti-aging performance with a lifespan of over 50 years.
- Strong corrosion resistance to inorganic acids, alkalis, and salts — ideal for industrial sewage transport.
- Smooth inner surface ensures low friction and steady water flow without blockage.
- High oxygen index and self-extinguishing performance for improved fire safety.
- Low thermal expansion coefficient — minimal deformation under temperature changes.
- Easy installation using adhesive joints; lightweight and simple to handle.
| Dn | S20 SDR41 PN5 | S16.7 SDR34.4 PN6 | S16 SDR33 PN6.3 | S12.5 SDR26 PN8 | S10 SDR21 PN10 | S8 SDR17 PN12.5 | S6.3 SDR13.6 PN16 | S6.3 SDR13.6 PN20 | S4 SDR9 PN25 |
|---|---|---|---|---|---|---|---|---|---|
| 10.00 | 1.50 | ||||||||
| 12.00 | 1.50 | ||||||||
| 16.00 | 1.50 | 1.80 | |||||||
| 20.00 | 1.50 | 2.30 | |||||||
| 25.00 | 2.80 | ||||||||
| 32.00 | 1.60 | 1.90 | 2.40 | 3.60 | |||||
| 40.00 | 1.50 | 1.60 | 1.90 | 2.40 | 3.00 | 4.50 | |||
| 50.00 | 1.60 | 2.00 | 2.40 | 3.00 | 3.70 | 5.60 | |||
| 63.00 | 1.60 | 1.90 | 2.00 | 2.50 | 3.00 | 3.80 | 4.70 | 7.10 | |
| 75.00 | 1.90 | 2.20 | 2.30 | 2.90 | 3.60 | 4.50 | 5.60 | 8.40 | |
| 90.00 | 2.20 | 2.70 | 2.80 | 3.50 | 4.30 | 5.40 | 6.70 | 10.10 | |
| 110.00 | 2.70 | 3.40 | 4.20 | 5.30 | 6.60 | 8.10 | 10.00 | ||
| 125.00 | 3.10 | 3.90 | 4.80 | 6.00 | 7.40 | 9.20 | 11.40 | ||
| 140.00 | 3.50 | 4.30 | 5.40 | 6.70 | 8.30 | 10.30 | 12.70 | ||
| 160.00 | 4.00 | 4.90 | 6.20 | 7.70 | 9.50 | 11.80 | 14.60 | ||
| 180.00 | 4.40 | 5.50 | 6.90 | 8.60 | 10.70 | 13.30 | 16.40 | ||
| 200.00 | 4.90 | 6.20 | 7.70 | 9.60 | 11.90 | 14.70 | 18.20 | ||
| 225.00 | 5.50 | 6.90 | 8.60 | 10.80 | 13.40 | 16.60 | |||
| 250.00 | 6.20 | 7.70 | 9.60 | 11.90 | 14.80 | 18.40 | |||
| 280.00 | 6.90 | 8.60 | 10.70 | 13.40 | 16.60 | 20.60 | |||
| 315.00 | 7.70 | 9.70 | 12.10 | 15.00 | 18.70 | 23.20 | |||
| 355.00 | 8.70 | 10.90 | 13.60 | 16.90 | 21.10 | 26.10 | |||
| 400.00 | 9.80 | 12.30 | 15.30 | 19.10 | 23.70 | 29.40 | |||
| 450.00 | 11.00 | 13.80 | 17.20 | 21.50 | 26.70 | 33.10 | |||
| 500.00 | 12.30 | 15.30 | 19.10 | 23.90 | 29.70 | 36.80 | |||
| 560.00 | 13.70 | 17.20 | 21.40 | 26.70 | |||||
| 630.00 | 15.40 | 19.30 | 24.10 | 30.00 |
Brass Compression Male Adapter (PE–Brass Fitting)
Brass PE Coupling (Female Thread Adapter)
Electrofusion 45° Elbow(Heavy Duty)
Electrofusion 90° Elbow
Electrofusion Equal Tee
Electrofusion Indicator Coupler
Electrofusion Reducer
Electrofusion Saddle Clamp
Electrofusion Scraper Tool
Electrofusion Tapping Saddle
HDPE Butt Fusion Cross (4-Way Cross Joint)
HDPE Electrofusion Elbow 45° (Heavy Duty)
HDPE Electrofusion Elbow 90° (Large Size)
HDPE Electrofusion Elbow 90° (Short Radius)
HDPE Flange Adapter (Stub End)
HDPE Threaded Male Adapter
HDPE Fittings
Ball Corks
Durable HDPE ball corks designed for smooth water flow control and easy shut-off in piping systems.
Female Elbows
HDPE elbows provide strong, leak-free directional changes for water and irrigation pipelines.
End Caps
Used to securely seal the end of HDPE pipes, preventing leaks and protecting the line from contamination.
Foot Valve
Prevents backflow in water suction lines, ensuring efficient and reliable water pumping operations.
Male Adapters
Connect HDPE pipes to threaded components or systems with a strong, watertight male-threaded end.
Male Elbows
Provide a threaded 90° connection between HDPE pipes and other fittings, ideal for compact installations.
PE Reducer Coupling
Join HDPE pipes of different diameters securely, maintaining steady flow and pressure balance.
Saddle clamps
Used to create branch connections or support HDPE pipelines, ensuring strong and stable installations.
Threaded Ball corks
Feature threaded ends for quick installation and easy flow control in pressurized HDPE pipe systems.
