Butt Fusion Machines
Our butt fusion machines create strong, seamless, and leak-proof joints in thermoplastic pipes for reliable pipeline systems. Designed for durability and precision, they are essential for ensuring the integrity and longevity of water, gas, and industrial infrastructure.
- Easy to handle, transport, and install
- Highly corrosion and abrasion resistant
- Weatherproof for underground applications
- Maintains water taste and quality — safe for drinking water
- Withstands high impact and underground movement without cracking
- Reliable supply and delivery across Rwanda.
- On-site technical and installation guidance.
- Dedicated after-sales and customer service team.
- Wide network of distributors for faster access.
- Consistent quality and support for every project size.
- Water Infrastructure: Used for municipal water supply systems, distribution mains, raw water intake lines, and wastewater/sewage transport to prevent leakage and root intrusion.
- Gas Distribution: Essential for natural gas pipelines due to their ability to create seamless, airtight joints, which is critical for safety and preventing gas leakage.
- Industrial Applications: Used in chemical processing plants, mining operations (for transporting abrasive slurries and chemicals), power generation (cooling water systems), and industrial cooling systems where chemical resistance is vital.
- Agriculture and Mining: Utilized for large-scale irrigation systems, dust suppression systems, and dewatering in mines.
- Civil Engineering: Used in diverse utility projects, including installation under roads (e.g., via horizontal directional drilling) due to the joint’s flexibility and resistance to ground movement.
- Material Compatibility: Designed primarily for Polyethylene (PE100, PE80, PE4710), Polypropylene (PP), and Polyvinylidene Fluoride (PVDF).
- Key Performance Parameters: The machines must precisely control the following:
- Heater Plate Temperature: Typically maintained within a range of 200°C to 240°C (392°F to 464°F), with stability within a narrow tolerance (e.g., ±3°C).
- Interfacial Pressure: Varies significantly by standard (e.g., 0.15 MPa for Low Pressure, 0.40–0.60 MPa for High Pressure) and is crucial for forming a proper weld bead and molecular diffusion.
- Soak Time and Cooling Time: Parameters are calculated based on pipe wall thickness and diameter to allow sufficient molecular entanglement and cooling under pressure.
- Data Logging: Modern semi-automatic and fully automatic machines are often equipped with GPS and data loggers (compliant with ISO 12176-4) to record all weld parameters for quality assurance and traceability.
- Joint Integrity: When performed correctly, the resulting joint is a “monolithic” structure with the same pressure rating and strength characteristics as the parent pipe material, resisting end loads and eliminating the need for thrust blocks.
- Available Diameters: Machines are available to cover a vast range of pipe sizes, from small manual machines for 16 mm pipes up to massive machines for pipes exceeding 1600 mm (over 60 inches).
Hydraulics & Pipeline Accessories
Butt Fusion Machine – Gearbox & Clamp Assembly
Butt Fusion Machine Clamp Assembly – Close-Up Technical View
Butt Fusion Welding Machine – Full Set (Large Diameter)
Butt Fusion Welding Machine – Full Set with Aluminum Inserts (Different Angle)
Butt Fusion Welding Machine – Full Set with Insert Clamps
Close-Up of Fusion Machine Clamping Unit
CNC Butt Fusion Welding Machine – Full Kit (Front View)
CNC Butt Fusion Welding Machine – Full Set (Large Diameter)
CNC Hydraulic Butt Fusion Machine – Full Kit
Electrofusion Controller – HST 315 (Portable Unit)
Electrofusion Controller – HST 315S (Compact Version)
Electrofusion Welding Control Unit – Portable Case Model
Electrofusion Welding Machine – EF100 Series (Portable Unit)
Electrofusion Welding Machine – HST 300 (Blue Housing)
Electrofusion Welding Machine – HST 300 (Yellow Housing)
Electrofusion Welding Wire Coil
Hydraulic Butt Fusion Machine – Complete Kit with Tool Box
Hydraulic Butt Fusion Machine – Complete Professional Kit
Hydraulic Butt Fusion Machine – Full Set with Storage Boxes
Hydraulic Butt Fusion Welding Machine – Complete Set
Hydraulic Butt Fusion Welding Machine – Full Kit (Side View)
Hydraulic Butt Fusion Welding Machine – Full Set (Front View)
Hydraulic Butt Fusion Welding Machine – Full Set (Large Diameter)
Large-Diameter Butt Fusion Welding Machine – Complete Kit
Manual Butt Fusion Machine (Medium Diameter)
Manual Butt Fusion Welding Machine – Front View
Manual Pipe Squeeze-Off Tool
Pipe Lifting & Handling Crane (Manual Trailer Type)
